Optical cohrence tomography (OCT)

Application and development of ultrafast MHz OCT systems

OCT is a noninvasive Imaging modality which is typically used for high resolution (~10µm), three dimensional imaging of scattering tissue. By using home built FDML laser technology we achieve imaging speeds of several million depth scans per second, which is one to two orders of magnitude higher than current commercially available systems (MHz-OCT).

These high imaging speeds already proved to be very useful in clinical applications, by reducing acquisition times and therefore reducing motion artifacts. But the high speed also gives access to the phase of the detected light and will thus allow the use of new numerical approaches for image quality enhancement and functional imaging with Swept-Source-OCT.

Our working group is conducting research in the field of OCT to develop new technologies and to identify possible fields of application.

The focus areas are:

  • MHz-OCT - Ultra-fast OCT imaging with several million depth scans per second
  • LARA-OCT - Large area robotically assisted OCT
  • VR-OCT - Real-time computation and rendering of entire OCT volumes in a virtual environment
  • Eye OCT - application of MHz-OCT to the eye for visualization of the retina or the anterior segment of the eye
  • Phase sensitive OCT - enhancement of the information content of an OCT image by adding phase contrast
  • Multispectral OCT - combination of RGB and OCT images for improved visualization of morphological structures
